MSI PRO H810M-E DDR5 LGA1851 mATX Motherboard
Please sign in so that we can notify you about a reply
Technical Specifications
| Attribute | Detailed Specification |
| Product Full Name | MSI PRO H810M-E DDR5 LGA1851 Micro-ATX Motherboard |
| Product Model / SKU | PRO H810M-E |
| Brand / Manufacturer | MSI (Micro-Star International) |
| Product Series | MSI PRO Series (Business & Everyday Productivity) |
| Form Factor | Micro-ATX (mATX) Architecture (Approx. 24.4 cm × 21.1 cm) |
| CPU Socket | Intel LGA1851 |
| Supported Processors | Intel Core Ultra Desktop Processors (Series 2 / Arrow Lake-S Architecture) |
| Chipset | Intel H810 Express Chipset |
| Memory Architecture | Dual-Channel DDR5 Memory Support |
| Memory Slots (DIMM) | 2 × DDR5 DIMM Sockets |
| Maximum Memory Capacity | Up to 128 GB (Supports 24GB / 48GB / 64GB Non-Binary Modules) |
| Memory Clock Speeds | Supports JEDEC Standard & Intel XMP 3.0 OC Modules (Up to 6400+ MT/s OC) |
| PCIe Expansion Slots | 1 × PCIe 4.0 x16 Slot (Reinforced Steel Slot / CPU Lane) 1 × PCIe 3.0 x1 Slot (Chipset Lane) |
| On-Board Graphics Interfaces | 1 × HDMI 2.1 Port (Supports 4K @ 60Hz) 1 × D-Sub (VGA) Legacy Port |
| M.2 Storage Interfaces | 1 × M.2 Slot (PCIe 4.0 x4 Mode, Key M, Supports Type 2242 / 2280 Storage Devices) |
| SATA Storage Interfaces | 4 × SATA 6Gb/s Ports (Supports Standard 2.5" / 3.5" Storage Drives) |
| Audio Chipset & Channels | Realtek High Definition 7.1-Channel Surround Audio Codec with Dedicated Audio Capacitors |
| Ethernet LAN | Realtek Gigabit (1GbE) Ethernet LAN Controller |
| Rear I/O Ports | 1 × HDMI 2.1 Output 1 × VGA (D-Sub) Output 2 × USB 3.2 Gen 1 (5Gbps) Type-A Ports 4 × USB 2.0 Type-A Ports 1 × RJ-45 Gigabit Ethernet Port 1 × PS/2 Mouse/Keyboard Combo Port 3 × 3.5 mm High Definition Audio Jacks |
| Internal Headers & Connectors | 1 × 24-Pin ATX Main Power Connector 1 × 8-Pin ATX 12V CPU Power Connector 1 × 4-Pin CPU Fan Header 1–2 × 4-Pin System Fan Headers 1 × USB 3.2 Gen 1 Header (Supports 2 Additional USB 3.2 Ports) 2 × USB 2.0 Headers (Supports 4 Additional USB 2.0 Ports) 1 × Front Panel Audio Header (JAUD1) 1 × Front Panel System Header (JFP1) 1 × Chassis Intrusion Header 1 × TPM 2.0 Module Header |
| Diagnostic Utilities | MSI EZ Debug LED (CPU, DRAM, VGA, BOOT Status Indicators) |
| Power & Hardware Technologies | Core Boost Technology, Memory Boost Fully Isolated Trace Layout, Heavy Plated Heat Sinks |
| BIOS Type & Features | UEFI AMI BIOS, Click BIOS, Hardware Monitor, Resizable BAR Support |
| Operating System Support | Windows 11 64-Bit Ready |
| Warranty Policy | 3 Years Official Manufacturer / Distributor Replacement & Service Warranty |
Product Description
The MSI PRO H810M-E DDR5 LGA1851 Micro-ATX Motherboard is an enterprise-grade, cost-effective computing foundation engineered for business workstations, commercial office fleets, school computer labs, and entry-to-mid level custom desktop builds. Designed on the space-saving micro-ATX form factor, the board delivers broad compatibility across standard mini-tower and mid-tower PC cases while retaining the critical interfaces required for high-efficiency daily operation. Dressed in the signature MSI PRO Series clean, matte-black aesthetic, it offers an understated and organized look built around long-term stability and hardware endurance.
The board is powered by the Intel H810 chipset and houses the Intel LGA1851 socket, providing native support for Intel Core Ultra desktop processors (Series 2 / Arrow Lake-S). Engineered with MSI Core Boost architecture and optimized multi-phase power delivery, it channels clean, uninterrupted electrical current to the CPU to sustain stable clock speeds under heavy data compilations and multitasking workloads. The dual-DIMM memory architecture supports high-bandwidth DDR5 modules up to 128GB, enhanced by MSI Memory Boost technology that uses fully isolated signal paths to minimize electromagnetic interference and ensure stable data throughput with Intel XMP profiles.
Storage and expansion capabilities are tailored for rapid modern workflows, featuring a dedicated high-speed PCIe 4.0 x4 M.2 NVMe slot for quick system boot drives alongside 4 standard SATA 6Gb/s ports for mass storage arrays. A reinforced PCIe 4.0 x16 slot accommodates discrete graphic solutions and expansion cards with enhanced physical retention. Video output versatility is maintained via an HDMI 2.1 port for modern 4K digital displays paired with a legacy VGA (D-Sub) connection for older office monitors. Equipped with Realtek Gigabit LAN, 7.1-channel HD Audio with isolated grounding, EZ Debug diagnostic LEDs for rapid hardware troubleshooting, and a 3-year official warranty, the MSI PRO H810M-E offers a rock-solid, future-ready LGA1851 platform for everyday computing reliability.
