Technical Specifications
| Attribute | Detailed Specification |
| Product Full Name | ASUS RT-BE92U BE9700 Tri-Band WiFi 7 10G Extendable AiMesh Router |
| Model & Part Number | RT-BE92U / 90IG0950-MO9A0V |
| Brand / Manufacturer | ASUS |
| Product Series | ASUS High-Performance Networking / WiFi 7 Gaming & Smart Home Series |
| Router Type | Tri-Band Wireless Gigabit & 10G Extendable AiMesh Gaming Router |
| Color | Black (Matte Textured Gaming Finish with Angular Accents) |
| Wifi Generation | WiFi 7 (802.11be) |
| Wireless Networking Standard | IEEE 802.11be (WiFi 7), IEEE 802.11ax (WiFi 6/6E), IEEE 802.11ac (WiFi 5), IEEE 802.11n (WiFi 4), IEEE 802.11a/b/g, IPv4, IPv6 |
| Band | Tri-Band (2.4 GHz + 5.0 GHz + 6.0 GHz) |
| Data Transfer Rate | BE9700 (Up to 9700 Mbps Total Throughput: 1032 Mbps on 2.4 GHz + 2882 Mbps on 5 GHz + 5764 Mbps on 6 GHz) |
| Antena | 4 × External High-Gain Adjustable Antennas + 1 × Internal High-Efficiency Antenna (with High-Power FEMs) |
| Transmit / Receive Streams | 2.4 GHz (3×3) + 5 GHz (2×2) + 6 GHz (2×2) |
| Mimo Technology | MU-MIMO Technology (Multi-User Multiple-Input Multiple-Output) & OFDMA |
| Mesh Technology | ASUS Smart AiMesh Technology (Wireless Backhaul, 10G Wired Backhaul, 2.5G Wired Backhaul) |
| Wan Network Standard | 10G / 2.5G / 1G / 100M Auto-Sensing Multi-Gigabit WAN (Supports Dual WAN Configurations) |
| Lan Network Standard | 10G / 2.5G / 1G / 100M Multi-Gigabit Ethernet Standards |
| Number Of Lan Port | 4 Ports Total: 1 × 10 Gbps (Configurable WAN/LAN) + 3 × 2.5 Gbps Dedicated LAN Ports (Plus 1 × 2.5 Gbps WAN/LAN) |
| Outdoor Range / Coverage | Up to 2,750 Square Feet (Approx. 255 m² / Up to 3–4 Rooms Whole-Home Coverage) |
| No. Of Current User | 100+ High-Bandwidth Connected Devices / Concurrent Heavy Client Sessions |
| WiFi 7 Core Advancements | Multi-Link Operation (MLO), 4096-QAM (4K-QAM), Ultrawide 320 MHz Channel Width on 6 GHz |
| Processor Architecture | 2.0 GHz Quad-Core High-Performance 64-Bit Network Processing Unit (SoC) |
| System Memory (RAM) | 1 GB High-Speed DDR4 RAM |
| Onboard Flash Storage (ROM) | 256 MB High-Speed Flash ROM |
| Operating Modes | Wireless Router Mode, AiMesh Node Mode, Access Point (AP) Mode, Media Bridge Mode, Repeater / Range Extender Mode |
| Smart Home Master & IoT Support | Up to 3 Dedicated SSIDs for IoT Devices, Kid's Network, and VPN Network Subnets |
| Guest Network | Up to 6 Guest Networks Supported (Guest Network Pro Subnets with Isolated Local LAN Access) |
| USB Connectivity & Applications | 1 × USB 3.2 Gen 1 Type-A Port (Supports 4G/5G Mobile Tethering, AiDisk, Samba, FTP, Download Master, Time Machine) |
| Commercial-Grade Security | ASUS AiProtection Pro Powered by Trend Micro (Lifetime Subscription-Free Security Suite) |
| Security Scanning & Defense | Router Security Assessment, Malicious Site Blocking, Two-Way Intrusion Prevention System (IPS), Infected Device Isolation |
| Wireless Encryption Standards | WPA3-Personal, WPA2-Personal, WPA/WPA2-Enterprise, Open System & OWE, WPS Support |
| Privacy & Secure DNS | DNS-over-TLS (DoT), Let's Encrypt Integration, Built-in SPI Firewall, Instant Guard Mobile VPN |
| VPN Support & Compatibility | Multi-VPN Support, VPN Fusion (Simultaneous Regular and VPN Tunnel Routing) VPN Client: WireGuard, OpenVPN, L2TP, PPTP, Surfshark VPN Server: WireGuard, OpenVPN, IPSec, PPTP |
| Parental Controls | Safe Browsing, Customized Internet Schedule, Preset Age-Level Profiles, Web & App Content Filters, Time Scheduling |
| Traffic Prioritization & QoS | Adaptive QoS, Bandwidth Limiter (Max 32 Rules), Traditional QoS, Traffic Analyzer, Real-Time Traffic Monitor |
| Advanced Wireless Technologies | OFDMA, Explicit & Universal Beamforming, Smart Connect, Airtime Fairness, UTF-8 SSID, RADIUS Client |
| Network Management & Tools | Port Forwarding (Max 64 Rules), Port Triggering (Max 32 Rules), DMZ, DDNS, MAC Address Filter (Max 64 Rules) |
| NAT Passthrough Support | PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE Relay |
| LAN & Streaming Features | IGMP Snooping, IPTV Passthrough Support, Manually Assign IP (Max 128 Rules), Wake on LAN (WOL), DHCP Server |
| Physical Controls & LED Indicators | WPS Button, Reset Button, Power Switch; LEDs: Power, WAN, LAN, 2.4GHz, 5GHz, 6GHz |
| Target Workload Applications | 8K Video Streaming, Cloud & HDR Gaming, Content Creation, GenAI Workloads, High-Density Smart Homes |
| Management Interfaces | ASUS Router Mobile App (iOS / Android) & Comprehensive ASUSWRT Web GUI |
| Power Supply Unit | External AC Power Adapter (Input: 110–240 VAC, 50/60 Hz; Output: 12V DC, Max 3.0A) |
| Product Dimensions (W × D × H) | 247.18 mm × 101.59 mm × 287.47 mm (9.73" × 4.00" × 11.32") |
| Product Net Weight | Approx. 790 g |
| Package Contents | 1 × ASUS RT-BE92U WiFi 7 Tri-Band Router 1 × RJ-45 Gigabit/Multi-Gig Ethernet Cable 1 × Wall Mount Bracket Kit 1 × Power Adapter 1 × Quick Start Guide 1 × Warranty Card |
| Warranty | 3 Years Standard ASUS Brand Warranty |
Product Description
The ASUS RT-BE92U is a high-performance BE9700 tri-band WiFi 7 gaming and extendable mesh router engineered for demanding smart homes, enthusiast gaming stations, professional creative studios, and multi-gigabit fiber broadband environments. Finished in an upright matte black chassis with angular thermal ventilation grilles and versatile wall-mounting capability, the router is equipped with four external adjustable high-gain antennas and an internal antenna system powered by high-power front-end modules. This antenna configuration eliminates directional blind spots and delivers up to 2,750 square feet of signal coverage.
At the core of the system is a 2.0 GHz 64-bit quad-core processor paired with 1GB of high-speed DDR4 RAM and 256MB of flash storage. This processing foundation manages dense multi-client traffic queues, complex firewall rules, and active encryption tunnels without packet loss. Operating on the latest IEEE 802.11be WiFi 7 standard across the 2.4 GHz, 5.0 GHz, and 6.0 GHz frequency bands, the RT-BE92U delivers aggregated wireless speeds up to 9700 Mbps—comprising 5764 Mbps on the 6 GHz band, 2882 Mbps on the 5 GHz band, and 1032 Mbps on the 2.4 GHz band. WiFi 7 enhancements include Multi-Link Operation (MLO) to aggregate and switch across bands simultaneously, 4096-QAM (4K-QAM) to increase data packing density by 20%, and ultrawide 320 MHz channel support on the clear 6 GHz band. These features deliver low-latency performance essential for 8K video streaming, competitive HDR gaming, and real-time AI cloud interactions.
Wired connectivity is built for high-speed fiber broadband and local network transfers. The router features a flexible 10 Gbps WAN/LAN port and a 2.5 Gbps WAN/LAN port supporting Dual WAN failover and link aggregation, complemented by three dedicated 2.5 Gbps Ethernet LAN ports for wired PCs, consoles, and NAS arrays. As an extendable router, it integrates ASUS Smart AiMesh technology, allowing flexible wired 10G or 2.5G Ethernet backhauls or wireless backhauls with compatible ASUS routers. A high-speed USB 3.2 Gen 1 port provides support for automated 4G/5G mobile phone tethering during ISP outages, as well as local cloud file storage via Samba and FTP servers. Five flexible operating modes—Wireless Router, AiMesh Node, Access Point, Media Bridge, and Range Extender—provide broad network deployment options.
Enterprise-grade network security is anchored by ASUS AiProtection Pro powered by Trend Micro, delivering lifetime subscription-free commercial protection featuring Two-Way IPS, malicious website blocking, and infected device isolation. Smart Home Master features allow administrators to separate up to 3 dedicated SSIDs for IoT ecosystems, children's profiles, and VPN-routed subnets, alongside support for up to 6 isolated guest networks. Privacy is reinforced by DNS-over-TLS (DoT) encryption, ASUS Instant Guard mobile VPN tunnels, and extensive Multi-VPN routing via VPN Fusion for WireGuard, OpenVPN, and IPSec protocols. Complete with age-tiered parental controls, Adaptive QoS traffic prioritization, NAT passthrough, and seamless mobile management via the ASUS Router App and ASUSWRT web portal, the ASUS RT-BE92U delivers a future-proof, multi-gigabit tri-band WiFi 7 foundation backed by ASUS's 3-year warranty.
