Mercusys MB130-4G Wireless Dual Band 4G LTE Router
Please sign in so that we can notify you about a reply
Specification
| Wireless | |
| Wireless Standards | IEEE 802.11ac/a/b/g/n |
| Frequency | 5 GHz, 2.4 GHz |
| WiFi Speeds | - 867 Mbps at 5 GHz |
| - 300 Mbps at 2.4 GHz | |
| Reception Sensitivity | - 11g 6Mbps: -95dBm |
| - 11g 54Mbps: -77dBm | |
| - 11n HT20 MCS7: -74dBm | |
| - 11n HT40 MCS7: -71dBm | |
| - 11a 6Mbps: -92dBm | |
| - 11a 54Mbps: -75dBm | |
| - 11ac VHT20 MCS8: -70dBm | |
| - 11ac VHT40 MCS9: -65dBm | |
| - 11ac VHT80 MCS9: -61dBm | |
| Transmission Power | - 2.4 GHz < 20dBm (EIRP) |
| - 5 GHz < 23dBm (EIRP) | |
| Wireless Security | WPA-PSK / WPA2-PSK |
| Wireless Functions | Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless, Statistics |
| Hardware | |
| Dimensions | 95×61.05×165.97 mm |
| Interfaces | - 1× 10/100Mbps LAN/WAN Port |
| - 1× 10/100Mbps LAN Port | |
| - 2× 4G/3G External Antenna Ports | |
| - 1× Nano SIM Card Slot | |
| Button | WPS/Reset Button |
| Ethernet Ports | - 1× 10/100 Mbps LAN/WAN Port |
| - 1× 10/100 Mbps LAN | |
| Network Type | - FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz) |
| - TDD-LTE: B38/B40 (2600/2300 MHz) | |
| - HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz) |
