GIGABYTE B650 AORUS ELITE AX V2 Motherboard Specification
Component | Details |
CPU | AMD Socket AM5, supports AMD Ryzen™ 7000/8000/9000 Series Processors |
Chipset | AMD B650 |
Memory | Supports DDR5 8000(OC) and beyond, up to 256GB; 4 x DDR5 DIMM sockets |
Graphics | Integrated AMD Radeon™ Graphics; 1 x DisplayPort 1.4 (3840x2160@144 Hz), 1 x HDMI 2.1 (4096x2160@60 Hz) |
Audio | Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel |
LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
Wireless Communication | Realtek Wi-Fi 6E RTL8852CE, Bluetooth 5.3, supports 2.4/5/6 GHz bands |
Expansion Slots | 1 x PCI Express x16 (PCIe 4.0/3.0); 2 x PCI Express x1 (PCIe 3.0) |
Storage Interface | 3 x M.2 connectors (PCIe 4.0/5.0); 4 x SATA 6Gb/s connectors |
RAID Support | RAID 0, RAID 1, RAID 10 for NVMe SSD and SATA storage devices |
USB Ports | Back Panel: 1 x USB Type-C® (USB 3.2 Gen 2), 2 x USB 3.2 Gen 2 Type-A, 5 x USB 3.2 Gen 1, 4 x USB 2.0/1.1; Internal: 1 x USB Type-C® (USB 3.2 Gen 2x2), 3 x USB 3.2 Gen 1, 4 x USB 2.0/1.1 |
Internal I/O Connectors | 1 x 24-pin ATX main power, 1 x 8-pin ATX 12V power, 1 x 4-pin ATX 12V power, 1 x CPU fan, 1 x CPU fan/water cooling pump, 3 x system fan, 1 x system fan/water cooling pump, 3 x addressable RGB Gen2 LED strip, 1 x RGB LED strip, 3 x M.2, 4 x SATA, 1 x front panel, 1 x front panel audio, 1 x USB Type-C® (USB 3.2 Gen 2x2), 1 x USB 3.2 Gen 1, 2 x USB 2.0/1.1, 1 x Trusted Platform Module, 1 x reset button, 1 x reset jumper, 1 x Clear CMOS jumper |
Back Panel Connectors | 1 x Q-Flash Plus button, 2 x SMA antenna connectors, 1 x DisplayPort, 1 x HDMI, 1 x USB Type-C® (USB 3.2 Gen 2), 2 x USB 3.2 Gen 2 Type-A, 5 x USB 3.2 Gen 1, 4 x USB 2.0/1.1, 1 x RJ-45, 3 x audio jacks |
I/O Controller | iTE® I/O Controller Chip |
Hardware Monitoring | Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control |
BIOS | 1 x 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus |
Bundled Software | Norton® Internet Security (OEM version), LAN bandwidth management software |
Operating System Support | Windows 11 64-bit, Windows 10 64-bit |
Form Factor | ATX, 30.5cm x 24.4cm |
GIGABYTE B650 AORUS ELITE AX V2 Motherboard
Unleash the Power of Next-Gen Performance
The GIGABYTE B650 AORUS ELITE AX V2 Motherboard is engineered for enthusiasts and gamers seeking top-tier performance and exceptional connectivity. Designed to support the latest AMD Ryzen™ 7000, 8000, and 9000 Series Processors, this motherboard provides a robust platform for both high-performance gaming and intensive multitasking.
Key Features of GIGABYTE B650 AORUS ELITE AX V2 Motherboard
- CPU Support: Compatible with AMD Ryzen™ 7000/8000/9000 Series Processors
- Chipset: AMD B650
- Memory: Supports DDR5 8000(OC) and beyond, up to 256GB
- Graphics: Integrated AMD Radeon™ Graphics, DisplayPort 1.4 and HDMI 2.1
- Audio: Realtek® Audio CODEC, High Definition Audio, up to 7.1-channel
- Networking: Realtek® 2.5GbE LAN, Wi-Fi 6E, Bluetooth 5.3
- Storage: Multiple M.2 and SATA options with RAID support
- USB Ports: Extensive USB connectivity including USB 3.2 Gen 2 and Gen 2x2
- Expansion Slots: PCIe 4.0 and PCIe 3.0 slots for versatile configurations
Why Buy from Nexus?
At Nexus, we offer the GIGABYTE B650 AORUS ELITE AX V2 with excellent customer support and competitive pricing. Our commitment to quality ensures you get the best components for your build, backed by a reliable warranty and dedicated service.
Ideal For
- Gamers: With support for high-speed DDR5 memory, integrated graphics, and PCIe 4.0, this motherboard provides an edge in gaming performance.
- Content Creators: The extensive connectivity options and high memory capacity make it perfect for video editing, 3D rendering, and other demanding applications.
- Enthusiasts: Overclocking capabilities and robust cooling solutions make it ideal for those who want to push their system to the limits.
Additional Benefits of GIGABYTE B650 AORUS ELITE AX V2 Motherboard
- Future-Proofing: With support for next-gen processors and high-speed memory, this motherboard is built to handle future upgrades.
- Enhanced Audio: Enjoy immersive sound with high-definition audio support, customizable through the audio software.
- Advanced Networking: Stay connected with high-speed LAN and the latest Wi-Fi 6E technology.
Technical Specifications of GIGABYTE B650 AORUS ELITE AX V2 Motherboard
CPU
- Socket: AMD Socket AM5
- Support: AMD Ryzen™ 7000/8000/9000 Series Processors
Memory
- Type: DDR5
- Max Capacity: 256GB
- Supported Speeds: Up to 8000(OC) MT/s
Onboard Graphics
- Integrated Graphics Processor: AMD Radeon™
- Display Outputs: 1 x DisplayPort, 1 x HDMI
Audio
- CODEC: Realtek® Audio
- Channels: Up to 7.1
Networking
- LAN: Realtek® 2.5GbE
- Wi-Fi: Realtek® Wi-Fi 6E
- Bluetooth: 5.3
Expansion Slots
- PCIe: 1 x PCIe 4.0 x16, 2 x PCIe 3.0 x1
Storage
- M.2 Slots: 3 x M.2 (PCIe 4.0/5.0)
- SATA: 4 x SATA 6Gb/s
USB Ports
- Type-C: USB 3.2 Gen 2x2
- Type-A: Multiple USB 3.2 Gen 1/2 and USB 2.0
Form Factor
- Type: ATX
- Dimensions: 30.5cm x 24.4cm
With the GIGABYTE B650 AORUS ELITE AX V2 Motherboard from Nexus, elevate your computing experience with superior performance, unparalleled connectivity, and future-ready technology. Whether you are building a gaming rig, a workstation, or a high-performance desktop, this motherboard is your ideal choice.
What is the price of GIGABYTE B650 AORUS ELITE AX V2 Motherboard in Bangladesh?
The latest price of GIGABYTE B650 AORUS ELITE AX V2 Motherboard in Bangladesh is 33,500৳. You can buy the GIGABYTE B650 AORUS ELITE AX V2 Motherboard at best price from our website or visit any of our showrooms.
