Lenovo IdeaCentre AIO 24ILL11 Core Ultra 5 226V 23.8" FHD All-in-One PC
Please sign in so that we can notify you about a reply
Technical Specifications
| Attribute | Detailed Specification |
| Product Full Name | Lenovo IdeaCentre AIO 24ILL11 23.8" FHD Intel Core Ultra 5 226V All-in-One Desktop PC |
| Model & Part Number (MPN) | IdeaCentre AIO 24ILL11 / F0JY001JLK |
| Brand / Manufacturer | Lenovo |
| Product Category | Sleek All-in-One (AIO) Desktop PC / Home Office & Modern Enterprise Workstation |
| Colorway & Surface Finish | Cloud Grey / Luna Grey; Clean Textured Matte Minimalist Finish |
| Form Factor & Design | Ultra-Slim All-in-One Chassis with Narrow Borders & Sculpted Architectural Metal-Reinforced Stand |
| Processor Brand & Family | Intel Core Ultra 200V Series (Lunar Lake Architecture / High-Efficiency Hybrid Computing) |
| Processor Model | Intel Core Ultra 5 226V Processor |
| Core & Thread Configuration | 8 Cores (4 Performance Cores + 4 Low Power Efficient Cores), 8 Threads |
| Processor Clock Speeds | Up to 4.50 GHz Max Turbo Frequency |
| CPU Cache & Architecture | 8 MB Intel Smart Cache; Ultra-Efficient System-on-Chip (SoC) Platform |
| AI Neural Processing Unit (NPU) | Integrated Intel AI Boost NPU Delivering up to 40+ TOPS Dedicated Neural Compute (Copilot+ Ready) |
| Graphics Processor | Integrated Intel Arc Graphics 130V (8 Xe2-Cores / Next-Gen Xe2 Architecture) |
| Installed System Memory (RAM) | 16 GB High-Speed LPDDR5X-8533 MHz Memory (Package-on-Package / MoP Memory-on-Package) |
| Memory Architecture | Ultra-Low-Latency Integrated On-Die Memory Subsystem |
| Primary Solid-State Storage | 512 GB M.2 2280 PCIe 4.0x4 NVMe Solid State Drive (SSD) |
| Storage Expansion Support | 1 × M.2 2280 PCIe 4.0 x4 Slot (Supports NVMe SSD Expansion up to 1TB / 2TB) |
| Display Panel Size & Type | 23.8-Inch Full HD Anti-Glare In-Plane Switching (IPS) Display |
| Bezel Design | 3-Side Borderless NearEdgeless Bezel Profile |
| Native Display Resolution | FHD (1920 × 1080 Pixels) 16:9 Aspect Ratio |
| Display Brightness & Refresh | 250 Nits Peak Luminance, Smooth 100 Hz Refresh Rate |
| Color Gamut & Eye Safety | 99% sRGB Wide Color Space; TÃœV Rheinland Low Blue Light & Flicker Free Certified |
| Audio Hardware & Processing | Dual Stereo Speakers (2 × 3W = 6W Total Output), Optimized with Harman Audio Tuning |
| Integrated Microphone | Dual-Microphone Array with AI Background Acoustic Noise Suppression |
| Integrated Web Camera | 5.0 MP + IR Hybrid Pop-up / Fixed Privacy Camera with Windows Hello Facial Recognition |
| Keyboard & Mouse Peripherals | Lenovo Wireless / Wired Ergonomic Keyboard & Optical Mouse Combo Included |
| Stand Ergonomics (Tilt) | Forward & Backward Tilt (-5° to +20°) |
| Integrated Stand Features | Built-in Smartphone / Tablet Holder Groove & Integrated Cable Management Routing |
| Wireless Connectivity | Wi-Fi 6 / Wi-Fi 6E (802.11ax 2×2 Dual-Band) + Bluetooth 5.3 Wireless Card |
| Ethernet & LAN | 1 × RJ-45 Gigabit Ethernet Port (100/1000M LAN) |
| USB Type-C Connectivity | 1 × USB-C (USB 10Gbps / USB 3.2 Gen 2) Supporting High-Speed Data Transfer |
| USB Type-A Connectivity | 1 × USB-A (USB 10Gbps / USB 3.2 Gen 2) + 2 × USB-A (USB 2.0 / USB 5Gbps for Peripherals) |
| Video Input & Output Ports | 1 × HDMI 1.4 / 2.1 Out Port + 1 × HDMI-In Port (Allows Using Monitor with External Laptops/Consoles) |
| Audio Interface | 1 × 3.5 mm Headphone / Microphone Audio Combo Jack |
| Security Hardware & Features | Discrete Firmware TPM 2.0 Enabled; Camera Hardware Privacy Shutter / Pop-up Mechanism |
| Power Supply Unit (PSU) | External 90W / 120W High-Efficiency AC Power Adapter |
| Operating System | Windows 11 Home Single Language |
| Product Dimensions (with Stand) | Approx. 540.0 mm × 192.0 mm × 431.0 mm (21.26" × 7.56" × 16.97") |
| Product Net Weight | Approx. 6.00 kg – 6.50 kg (Approx. 13.23 lbs – 14.33 lbs) |
| Environmental Certifications | ENERGY STAR 8.0, EPEAT Silver / Gold Registered, RoHS Compliant |
| Package Contents | 1 × Lenovo IdeaCentre AIO 24ILL11 Desktop Panel & Stand 1 × AC Power Adapter & Power Cord 1 × Wireless/Wired Keyboard 1 × Wireless/Wired Optical Mouse 1 × Quick Start Guide & Warranty Documentation |
| Warranty Policy | 2 Years Lenovo Limited Warranty (1 Year for Adapter & Bundled Accessories) |
Product Description
The Lenovo IdeaCentre AIO 24ILL11 (MPN: F0JY001JLK) is an all-in-one desktop PC designed for contemporary home offices, executive workstations, reception suites, and collaborative study environments that demand a clean, cable-free aesthetic combined with next-generation processing power. Finished in a minimalist Cloud/Luna Grey tone, the computer integrates the entire system directly into a slim 23.8-inch display enclosure supported by an architectural stand. The base includes a dedicated smartphone cradle dock to keep mobile devices visible during the workday, along with a concealed cable routing system to keep desk surfaces uncluttered.
Under the hood, the system is driven by the Intel Core Ultra 5 226V processor, featuring 8 hybrid computing cores (4 Performance cores and 4 Low Power Efficient cores) with turbo boost clock speeds reaching up to 4.50 GHz on Intel's power-efficient Lunar Lake architecture. Built with an integrated Intel AI Boost NPU delivering over 40 TOPS of dedicated neural compute, the machine handles on-device artificial intelligence workflows—including smart image generation, automated video noise removal, and Windows Copilot+ productivity features—with quiet thermal operation. Graphics are powered by the integrated Intel Arc 130V graphics engine utilizing the Xe2 architecture. The system features 16GB of high-speed LPDDR5X-8533 MHz memory directly integrated on-package alongside a fast 512GB PCIe 4.0x4 NVMe M.2 SSD, ensuring rapid application launches and responsive multitasking.
The visual display features a 23.8-inch Full HD (1920 × 1080) IPS panel framed by an ultra-thin 3-side NearEdgeless border. Boasting 250 nits of brightness, 99% sRGB color gamut coverage, a smooth 100Hz refresh rate for fluid cursor tracking, and TÜV Rheinland Low Blue Light certification, the screen reduces ocular strain during long work sessions. For versatile hybrid productivity, the PC includes an HDMI-In port that allows the panel to function as a standalone external monitor for laptops or gaming consoles. Video calls and multimedia are supported by a high-resolution 5.0 MP + IR camera with physical privacy protection and Windows Hello facial authentication, dual 3W stereo speakers tuned by Harman Audio, dual noise-canceling digital microphones, Gigabit Ethernet, fast Wi-Fi connectivity, and a matched keyboard and mouse set. The Lenovo IdeaCentre AIO 24ILL11 delivers a complete, space-saving desktop computing solution backed by Lenovo's 2-year warranty.
