AOC AGON AG493QCX 49" DQHD 144Hz 1ms Curved VA Gaming Monitor
Please sign in so that we can notify you about a reply
Technical Specifications
| Attribute | Detailed Specification |
| Product Full Name | AOC AGON AG493QCX 49.0" Dual QHD (DQHD) 144Hz 1ms Curved VA Super Ultrawide Gaming Monitor |
| Model | AG493QCX |
| Brand / Manufacturer | AOC |
| Product Series | AGON Flagship Esports & Simulation Gaming Lineup |
| Product Category | Super Ultrawide Curved Racing, Flight Sim & Multitasking Desktop Monitor |
| Screen Size (Diagonal) | 49.0 Inches (124.46 cm) |
| Panel Technology | Vertical Alignment (VA) Panel |
| Backlight Technology | White LED (WLED) Backlight |
| Curvature Radius | 1800R Panoramic Human-Eye Immersion Curvature |
| Active Display Area | 1195.8 mm (H) × 336.3 mm (V) (Equivalent to Two 27-inch 16:9 QHD Monitors Side-by-Side) |
| Bezel Design | 3-Sided Borderless / Ultra-Narrow Frameless Profile |
| Native Display Resolution | Dual QHD / DQHD (5120 × 1440 Pixels) |
| Aspect Ratio | 32:9 Super Ultrawide Panoramic Aspect Ratio |
| Pixel Pitch & Density | 0.2331 mm × 0.2331 mm (Approx. 109 PPI) |
| Peak Brightness | 350 Nits (cd/m²) Typical / up to 400 Nits Peak (HDR Mode) |
| Native Contrast Ratio | 3000:1 Typical Static Contrast Ratio |
| Dynamic Contrast Ratio (DCR) | 80,000,000:1 |
| Maximum Refresh Rate | 144 Hz (Fast Refresh Rate via DisplayPort 1.4) / Up to 120Hz via HDMI 2.0 |
| Response Time | 1 ms (MPRT) / 4 ms (GtG with Overdrive) |
| Viewing Angles | 178° Horizontal / 178° Vertical Wide Viewing Angles |
| Display Color Depth | 16.7 Million Colors (8-Bit) |
| Color Gamut Coverage | Approx. 120% sRGB, 90%–93% DCI-P3, 90% Adobe RGB |
| High Dynamic Range (HDR) | VESA DisplayHDR 400 Certified / HDR10 Support |
| Display Surface Finish | Anti-Glare Coating with 3H Hardness Haze Treatment |
| Variable Refresh Rate Tech | Adaptive-Sync (AMD FreeSync Premium Pro & G-SYNC Compatible) |
| Gaming Enhancements | Low Input Lag Mode, Dial Point (Crosshair Overlay), Shadow Control, Game Color Tuning, Frame Counter |
| Productivity & Multitasking | Built-in KVM Switch, Picture-in-Picture (PiP), Picture-by-Picture (PbP) Dual-System Display |
| Integrated Audio Speakers | Built-in Dual Stereo Speakers (2 × 5W = 10W Total Output) with DTS Sound Enhancement |
| Eye Safety Technologies | AOC Low Blue Mode (Hardware/Software Filter) & DC Flicker-Free Backlight Technology |
| DisplayPort Inputs | 2 × DisplayPort 1.4 Inputs (Supports Full 5120 × 1440 @ 144Hz) |
| Digital Video Inputs | 2 × HDMI 2.0 Ports |
| USB Hub System | Built-in USB 3.2 Hub (1 × USB-B Upstream + 3 × USB 3.2 Gen 1 Downstream Ports with Fast Charging) |
| Audio Interface | 1 × 3.5 mm Audio Out Line-Out Port (Headphone Jack) |
| Stand Ergonomics (Height Adjustment) | Up to 100 mm Height Lift Adjustment |
| Stand Ergonomics (Swivel) | Left & Right Swivel (-15° to +15°) |
| Stand Ergonomics (Tilt) | Forward & Backward Tilt (-3.5° to +13.5°) |
| Stand Base & Cable Management | Heavy-Duty Aluminum Stand with Integrated Cable Routing Aperture |
| VESA Wall Mount Compatibility | 100 mm × 100 mm Standard VESA Mount Interface |
| Physical Security | Integrated Kensington Security Lock Slot |
| Power Supply Type | Internal Integrated AC Power Supply Module |
| Voltage Requirement | 100 – 240 VAC, 50 / 60 Hz Universal AC Input |
| Power Consumption | Typical: 60W – 75W / Standby & Sleep: < 0.5W |
| Environmental Certifications | RoHS Compliant, CE, FCC, Energy Star Rated |
| Dimensions (with Stand) | Approx. 1194.4 mm × 467.6 – 567.6 mm × 364.5 mm (W × H × D) |
| Product Net Weight | Approx. 14.40 kg – 15.00 kg (with Heavy-Duty Stand Assembly) |
| Software Support | AOC G-Menu / i-Menu Desktop On-Screen Display Control Software |
| Package Contents | 1 × AOC AGON AG493QCX Monitor Panel 1 × Heavy-Duty Ergonomic Stand Base & Stem Assembly 1 × DisplayPort 1.4 Cable 1 × HDMI Cable 1 × USB Type-A to Type-B Upstream Cable 1 × AC Power Cable 1 × Quick Setup Guide & Safety Documentation |
| Warranty Policy | 3 Years AOC Brand Warranty |
Product Description
The AOC AGON AG493QCX is an expansive 49-inch super ultrawide curved gaming monitor engineered for sim racers, flight simulation enthusiasts, content creators, financial traders, and productivity power users seeking seamless panoramic immersion without distracting multi-monitor center bezels. Designed within AOC's premier AGON lineup, the monitor features a dark matte chassis supported by a heavy-duty, reinforced aluminum desktop stand. The expansive 3-sided borderless frame maximizes the field of view, while the robust stand offers height elevation, wide swivel, and tilt customization alongside a built-in cable pass-through channel to route heavy video and power cords neatly.
At the core of the display is a 49.0-inch Vertical Alignment (VA) panel with an 1800R curvature and a 32:9 aspect ratio at a native Dual QHD (DQHD) resolution of 5120 × 1440 pixels. Delivering the exact screen workspace of two 27-inch 16:9 QHD (2560 × 1440) monitors fused seamlessly into a single unbroken panel, it wraps around the user's natural field of peripheral vision for high immersion in open-world titles, simulators, and expansive timeline video editing suites. Visual execution is driven by a 144Hz refresh rate and a 1ms MPRT response time, ensuring fluid motion tracking and minimal ghosting during fast scene transitions. Backed by a 3000:1 native static contrast ratio, VESA DisplayHDR 400 certification, and over 120% sRGB color gamut coverage, the screen reproduces deep blacks, highlighted specular details, and rich color saturation. Visual tearing and frame stuttering are eliminated across fluctuating framerates using Adaptive-Sync technology, compatible with AMD FreeSync Premium Pro and NVIDIA G-SYNC pipelines.
For hybrid workflows and productivity, the monitor includes an integrated KVM switch paired with Picture-by-Picture (PbP) and Picture-in-Picture (PiP) display modes. This allows users to connect two separate PCs or laptops to the display and control both systems simultaneously using a single keyboard, mouse, and screen setup. Acoustic output is handled directly by built-in 5W × 2 stereo speakers enhanced with DTS Sound processing, providing clear desktop audio without external speakers. Hardware connectivity is extensive, featuring two DisplayPort 1.4 inputs, two HDMI 2.0 ports, a 3.5mm audio line-out jack, and a 3-port USB 3.2 Gen 1 downstream hub with fast-charging support. Completed with specialized gaming assists (Low Input Lag, Dial Point crosshair, Shadow Control), DC Flicker-Free backlighting, Low Blue Mode eye protection, 100 × 100 mm VESA mount compatibility, and desktop tuning via AOC G-Menu, the AOC AGON AG493QCX delivers an expansive, high-resolution gaming and workstation solution backed by AOC's 3-year warranty.
