GIGABYTE M27UP 27" 4K UHD 160Hz KVM Gaming Monitor
Please sign in so that we can notify you about a reply
Technical Specifications
| Attribute | Detailed Specification |
| Product Name | GIGABYTE M27UP Gaming Monitor |
| Model Designation | M27UP |
| Panel Size / Diagonal | 27 Inches (Flat Widescreen Layout) |
| Panel Display Lighting | Edge-lit LED Backlight |
| Panel Technology | SuperSpeed IPS (SS IPS) |
| Display Surface Treatment | Non-glare / Anti-reflection Matte Finish |
| Native Resolution | 4K UHD 3840 x 2160 Pixels (16:9 Aspect Ratio) |
| Pixel Pitch | 0.1554 x 0.1554 mm (High 163 PPI Density) |
| Max Refresh Rate | Native 4K UHD Mode: 160 Hz Tactical Dual Mode: 320 Hz at Full HD (1920 x 1080) |
| Response Time | 1ms GTG (Gray to Gray) |
| Typical Brightness | 350 cd/m² (Typical) |
| Static Contrast Ratio | 1000:1 |
| Color Support Depth | 10-bit (8-bit + FRC / 1.07 Billion Display Colors) |
| Color Gamut Saturation | Wide Palette: 95% DCI-P3 / 125% sRGB |
| High Dynamic Range | VESA DisplayHDR 400 Certified |
| Viewing Angles (H / V) | 178° Horizontal | 178° Vertical |
| Variable Refresh Tech | Adaptive-Sync Support (AMD FreeSync Premium / NVIDIA G-Sync Compatible) |
| I/O Connectivity Ports | 1x DisplayPort 1.4 (with DSC / HBR3) 2x HDMI 2.1 1x USB Type-C (Alt Mode, Upstream, Power Delivery up to 18W) 1x 3.5mm Earphone Audio Jack |
| USB Hub Interface | 3x USB 3.2 Gen 1 Downstream ports | 1x USB 3.2 Gen 1 Upstream port |
| Device Management KVM | Integrated Hardware KVM Switch with Tactical Switch 2.0 |
| Integrated Audio Speakers | Built-in Dual Stereo Speakers (5W x 2 High-Output Setup) |
| Proprietary Gaming Tools | OSD Sidekick, Tactical Dual Mode, Smart OD (Dynamic Overdrive), Aim Stabilizer Sync, Black Equalizer, GameAssist (Crosshair, Timer, Counter) |
| Eye Care Infrastructure | Flicker-Free technology, TÃœV Rheinland Certified Low Blue Light Mode |
| Mechanical Ergonomics | Fully Adjustable Stand: • Height Adjustment: Up to 130mm • Tilt: -5° to +21° • Swivel: ±15° • Pivot: 0° to +90° (Clockwise Vertical Layout) |
| VESA Wall Mounting | 100 x 100 mm Structural Grid Layout |
| Power Supply Matrix | Power Board Built-in Layout (Internal Power Supply, AC 100-240V ~ 50/60Hz) |
| Operational Power Draw | 27W (Typical Operational Draft) | 0.5W Standby | 0.3W Off-Mode |
| Physical Dimensions | With Stand: 612 x 515 x 192 mm Without Stand: 612 x 371 x 59 mm |
| Net Product Weight | 6.65 kg (With Stand Assembly) | 5.15 kg (Panel Only) |
| Warranty Package | 3 Years Limited Brand Warranty |
Product Description
The GIGABYTE M27UP 27" 4K UHD 160Hz KVM Gaming Monitor is an upper-tier hybrid display meticulously engineered to form an uncompromised bridge between ultra-sharp content creation, premium console play, and high-tier competitive PC esports. Anchored by a high-density 27-inch SuperSpeed IPS (SS IPS) flat display panel, it delivers a razor-sharp 4K Ultra HD (3840 x 2160) resolution, giving desktop configurations four times the detail density of standard Full HD monitors. What makes the M27UP uniquely lethal is its innovative Tactical Dual Mode via Tactical Switch 2.0. This allows players to drop their viewable area instantly to a cropped 24-inch layout, trading the native 4K 160Hz image for a blazing-fast Full HD 320Hz configuration tailored specifically for competitive first-person shooters. Backed by a true 1ms GTG response time, pixel transitions occur with absolute precision, completely deleting trailing white lines or ghosting artifacts.
Beyond pure competitive speeds, the M27UP excels as a productivity powerhouse and multi-system control station. It features an integrated hardware KVM Switch, empowering users to seamlessly operate multiple machines—such as a dedicated gaming desktop and a workstation laptop—using a single keyboard, video monitor, and mouse combo. Devices attach cleanly via an advanced I/O panel featuring dual HDMI 2.1 inputs, DisplayPort 1.4, and a multi-functional USB Type-C port supporting DP Alt Mode. Visuals look remarkably rich thanks to native 10-bit color depth supporting 1.07 billion colors, capturing a wide 95% DCI-P3 color gamut and achieving full VESA DisplayHDR 400 certification. Complete with premium dual 5W built-in speakers, AMD FreeSync/G-Sync adaptive pacing, an ergonomic stand supporting height, tilt, swivel, and full vertical pivot adjustments, and an official 3-year limited warranty, this monitor stands as an uncompromised centerpiece for any modern desktop layout.
